AA4C truck test lane for repair shop Automobile Roller Brake Tester Forces With Axle Load dual plates side slip tester 10T capacity

1. Product Features:

The inspection tester supports a maximum axle load of 10,000 kg.
The detection control system uses a high-brightness LED display for guidance and is controlled by an industrial-grade computer.
Integrated with smoke density, exhaust gas, and headlight detection functions; speedometer detection functionality is optional.
The detection system supports manual single-station, semi-automatic, and fully automatic operation modes.
Automatically prints and determines detection results, with fast query capabilities for detection data and records based on time, license plate, vehicle model, etc.
Equipped with the latest national standards, allowing users to modify detection criteria as needed.
Features high-speed system signal data acquisition; the braking process curve can be dynamically displayed on the software interface while operating the brake pedal.

2. Operation Interface:

3. Vehicle Inspection Login Interface:

4. Detailed Technical Parameters for Each Inspection Tester:

(1) AA-FZ-10T Brake Tester Technical Parameters:

Parameter	Value
Rated Load (t)	10
Wheel Brake Force Measurement Range (daN)	0-4000
Division Value (daN)	1
Indication Error	±3%
Roller Diameter (mm)	245
Roller Length (mm)	1100
Inner Span of Rollers (mm)	700
Outer Span of Rollers (mm)	2900
Roller Center Distance (mm)	470
Height Difference Between Front and Rear Rollers (mm)	30
Roller Surface Type	Sand-coated
Roller Sliding Friction Coefficient	≥0.85
Roller Surface Linear Speed (Km/h)	2.5
Third Roller Status	Available
Auxiliary Vehicle Exit Device	Airbag lifting
Power Supply (V)	AC380V 50Hz
Motor Power (KW)	11KW*2
Sensor Power Supply (V)	DC12
Calibration Ratio	10
Self-weight (Kg)	1800

(2) AA-CH-10 Side-Slip Test Platform Technical Parameters:

Parameter	Value
Model	AA-CH-10T
Rated Load (t)	10
Measurement Range (m/Km)	±10
Slide Plate Dimensions (mm)	1000*1100
Applicable Wheel Track (Inner/Outer) (mm)	700/2900
Relaxation Plate Dimensions (mm)	1100*250
Sensor Power Supply (V)	DC12
Sensor Output Signal (V)	0-12
Structure Type	Double-plate linkage
Self-weight (t)	0.85
